RunCam Split HD
Field of View(FOV) 154°
Horizontal Perspective 124°
Video Resolution
2.7K@60fps/1440P@60fps(4:3)
2.7K@60fps/1080P@60fps
FPV Resolution 720P@60fps
Video File Format MP4
Image Sensor SONY(5MP)
Communication Interface Supported
Max Micro SD Card Supported Up to 128G
Mounting Hole Distance 20*20mm / 25.5*25.5mm
PCB Size 29*30mm
Lens Module Size 19*19mm
Lens Specs M12*0.5
Power Input DC 5V
Working Current 450mA@5V(Max)
Weight 19.9g
© RunCam® Technology Co., Ltd.
SMART16 Caddx Ant FPV Camera
Model:Caddx Ant Camera
Image Sensor :1/3″ CMOs Sensor
Horizontal Resolution :1200 TVL
Video Standard : NTSC and PAL ( switchable )
OSD Support : Yes
Aspect Ratio :16:9 or 4:3
Synchronization : Internal
Electronic Shutter : PAL :1/50-100,000; NTSc :1/60-100,000
S / N Ratio :>52dB( AGc OFF )
Video Output : CVBS
Lens :1.8mm
Min. Illumination :0.001Lux@F1.2
Auto Gain Control : Yes
BLC : Yes
WDR : Global WDR
DNR :3D DNR
Dimensions :14:14mm( bracket to 19:19mm)
Power input :DC5-25V
Operable Temperature :-20℃-+60℃
Operable Humidity :20%-80%
Weight :2g( N . w .)
Size:14x14mm
© GEPRC
